TYM 3620H Tractor

By TYM

SKU: TYM3620HTL
$28,250.00

*Cash/Check Discounts available depending on the Model of Tractor – Credit Card Fee Applies. Contact store for details

Includes Tractor & Quick Attach Loader. High performance meets efficiency in this highly customizable Series 3 tractor that has the power to support your productivity. One of the strongest and toughest tractors in its horsepower range, this customizable tractor delivers power and dependability in its compact frame. The 35 HP 4-cycle engine matched with a…

Available

Contact Our Locations

Product Help Tractor Credit Application
Part
Compact Tractors, Tractors and Implements
Brand
TYM
Prop 65 Warning

California Residents:  Prop 65 WARNING

Additional Information

Includes Tractor & Quick Attach Loader.

High performance meets efficiency in this highly customizable Series 3 tractor that has the power to support your productivity.

One of the strongest and toughest tractors in its horsepower range, this customizable tractor delivers power and dependability in its compact frame. The 35 HP 4-cycle engine matched with a 4-range Hydro-Max HST or Synchro-Shuttle transmission can drive a range of implements to do everything from digging up rocks to hauling them off-site.

Heavy-duty 3-point hitch and stabilizers make the tractor a powerful partner on the field or on-site, while the high-capacity front-end loader attachment boosts productivity by helping you move more at once. The 2-speed independent PTO allows you to operate attachments with greater fuel efficiency and without compromising productivity.

Equipped with a naturally aspirated engine designed and manufactured by TYM, the tractor is designed to be eco-friendly and fuel-efficient but makes no compromise on performance and reliability.

The tilt steering wheel allows operators to adjust the position of the steering wheel for a more comfortable driving experience.

Safety is always first. The PTO switch ensures the safe operation of all tractor attachments.

The differential lock system activated with easily accessible levers provides enhanced traction in slippery work environments. 52˚ turning angle makes operation in narrow areas much easier.

The water-separating fuel filter prevents foreign substances from entering the fuel, ensuring better engine start ability and preventing damage to the machine.

In addition to standard agricultural tires, industrial and turf tires are also available for versatile working conditions.

Engine

Engine manufacturerTYM A1700N2
TypeNatural Aspiration
Gross engine power35 hp | 26.0 kW
PTO power29.6 hp | 22 kW
Rated engine speed2500 rpm
No. of cylinders3
Displacement104.5 cu. in.
Air cleanerDry Element
Alternator12V, 50A
Fuel systemIDI

Powertrain

Transmission typeHST
No. of speedsF4xR4 (4-Range)
Max. traveling speed19.5 mph
BrakesWet, Multi-disc
SteeringHydrostatic
ClutchNo

Hydraulic System

Pump typeSingle Gear Pump
Implement flow4.3 gpm
Steering flow8 gpm
Total flow12.3 gpm
Category, 3-point hitchI
Hitch lift capacity3306 lb
Front Loader Lift Capacity2701 lb
Hitch lift capacity at 24 inches behind link ends2425 lb
Lift control typePosition
No. of standard remote valvesOptional (up to 4)

PTO

PTO typeIndependent
PTO controlWet, Multi-Disc
PTO rear584 rpm

Capacities

Fuel tank11.8 gal
Coolant6 qt
Crankcase4.5 qt
Transmission/Hydraulics system11.1 gal
Front axle1.8 qt

Dimensions & Weights

Overall length with 3-point hitch127.4 in.
Overall width64.9 in.
Wheelbase71.1 in.
Height to top of ROPS98.4 in.
Min. ground clearance15.5 in.
Min. turn radius with brakes9.2 ft
Min. turn radius without brakes9.2 ft
Weight with ROPS3754 lb

Standard Tires

R1 Agricultural – Front9.5-16
R1 Agricultural – Rear12.4-28
R3 Turf – Front27×8.5-15 / 29×12.5-15
R3 Turf – Rear41×14-20 / 44×18-20
R4 Industrial – Front10×16.5
R4 Industrial – Rear420/70×24
