Branson 2505 Tractor

Product Help

Overview

The Branson 2505 tractor is designed with dependability in mind by our best at Branson Manufacturing of South Korea, a leader in the field of agricultural equipment with over fifty years experience. So, you can rest assured in knowing you’re getting a quality built tractor, assembled right here in the United States at our plants in Georgia, Oregon, and Texas.

Branson 2505 Tractor Features

  • 2 Range HST Transmission
  • Hydrostatic Steering and Cruise Control
  • One Touch ON/OFF switch
  • Quick Disconnect Loader with Level Indicator and Loader Valve with “Float Position”

Engine

  • Engine Model Yanmar 3TNV80F NXDKTF
  • Aspiration Natural
  • Emissions Standards Tier 4
  • Engine Gross Power 24.7 hp (18.4 kW)
  • PTO Power 18.8 hp (14.0 kW)
  • No. of Cylinders 3
  • Displacement 77.3 cu.in (1,267 cc)
  • Rated Revolution 3000 RPM
  • Fuel Tank Capacity 5.8 gal (22 L)
  • Air Cleaner Dry, Element
  • Alternator – 12 Volt amp 40

Drivetrain

  • Transmission hst
  • Forward/Reverse Method hst
  • 4 Wheel Drive 2WD/4WD
  • No. of Traveling Speeds 2 Range
  • Forward Traveling Speed 11.0 mph (17.7 km/h)
  • Reverse Traveling Speed 11.2 mph (18.1 km/h)
  • Clutch No
  • Brake Wet, Multi-disc
  • Differential Lock STD
  • Cruise Control Standard

Hydraulics

  • Loader lift capacity to full height 992 lbs
  • Steering Power Assisted Hydrostatic
  • Total Hydraulic Flow (POWER STEERING+Implement) 7.0(2.8+4.2) gpm/
  • 25.7(10.5+15.8) lpm
  • Lift Control Type Position
  • Joystick Valve No
  • Rear Remote (Port) Option (Up to 2)

3 Point Hitch

  • 3 Point Hitch CAT I
  • Lift capacity at lift link ends 1,214 lbs (551 kg)
  • 3Point Hitch Lift Capacity @24″ behind lift point 1,101 lbs (499 kg)

PTO

  • Rear (Mid) PTO Speed 540 (2,000 RPM)
  • Rear PTO Type Independent
  • Clutch –

Tires

  • AG Front 6 – 12
  • AG Rear 9.5 – 16
  • Turf Front 20×8.00-10
  • AG Rear 29×12.5-15
  • Ind. Front 23 x 8.50 – 12
  • AG Rear 12 – 16.5

Branson 2505 Tractor Dimensions

  • Wheelbase 57.5 in (1,460 mm)
  • Overall Length (W/ 3PT) 100.5 in (2,553 mm)
  • Min.Overall Width 45.8 in (1.164 mm)
  • Overall Height (W/ ROPS) 91.3 in (2,320 mm)
  • Ground Clearance (4WD) 9.5 in (240 mm)
  • Min.Turning Radius (W/ Brake) 8.32 ft (2.54 m)
  • Weight (W/O Front Weights) 1,638 lbs (743 kg)

Check out the largest selection of Branson tractors in the San Francisco Bay Area available only at Campway’s Truck Accessory World!
